Indicators

Digital Indicator

Long Stroke



Code_No Measuring
Range 		Accuracy Least Count
IDL100001 0-100 ± 0.008 0.001
IDL10001 0-100 ± 0.05 0.01
IDL50001 0-50.8 ± 0.006 0.001
IDL5001 0-50.8 ± 0.03 0.01
All Values in mm
Inspection Report with Declartion of conforming
MM/Inch Conversion
Suited Plastic Case
Battery 3V CR1632 Lithium ION
low power consumption with long battery life
Data output convenient for relative and absolute measurement conversion
LCD-20mm
Accurate reading when turned on
