Micrometers

outside micrometer

Code_No	Measuring Range	Accuracy	A	B	D	L	Least Count
MO300	275-300	±0.009	169	17	68	307	0.01
MO275	250-275	±0.009	158	17	68	281	0.01
MO250	225-250	±0.008	147	17	68	256	0.01
MO225	200-225	±0.008	132	17	68	231	0.01
MO200	175-200	±0.007	124	17	68	206	0.01
MO175	150-175	±0.007	108	17	68	181	0.01
MO150	125-150	±0.006	94	17	68	156	0.01
MO125	100-125	±0.006	80	17	68	131	0.01
MO100	75-100	±0.005	64	17	68	106	0.01
MO75	50-75	±0.005	54	17	68	81	0.01
MO50	25-50	±0.004	42	17	68	56	0.01
MO25	0-25	±0.004	27	17	68	31	0.01

All Values in mm

Suited Plastic Case

Wooden Case

Tungsten Carbidde Tipped

Supplied With Setting Anvils[Except 0-25]

Ratchet Stop

fitted with locking mechanism
