Non-Standard Calipers

Inside dial snap gauge

Code_No	Measuring Range	Accuracy	H	L	R	S	Least Count
SYIS25	5-25	± 0.03	1.5	35	0.3	1	0.01
SYIS30	10-30	± 0.03	3.5	55	0.5	2	0.01
SYIS40	20-40	± 0.03	6.5	80	0.5	3	0.01
SYIS50	30-50	± 0.03	8.5	80	0.5	3	0.01
SYIS60	40-60	± 0.03	8.5	80	0.5	3	0.01

All Values in mm

Hardened Stainless Steel

rotating dial with lock

Aluminium Case
